Up Paper Flow Wrap Machine
| Up paper fiow wrap machine | |||||||
| Model | 250B/D | 250E/S | 320B/D | 350B/D | 400-B/D | 450D | 600D |
| Film Width | Max.250mm | Max.180mm | Max.320mm | Max.350mm | Max.400mm | Max.450mm | Max.600mm |
| Bag Width | 30-110mm | 40-160mm | 40-185mm | 50-210mm | 50-285mm | ||
| Bag Length | 65-190mm/120-280mm | 50-115mm/45-90mm | 65-190mm/120-280mm/90-220mm/150-330mm | 130-450mm/150-450mm/180-580mm | |||
| Product High | Max.35/50mm | Max.35mm | Max.35/50mm | Max.45/60mm | Max.60/80/100/140mm | ||
| Speed | 40-230bags/min | 60-330bags/min | 40-230bags/min | 30-180bags/min | 30-180bags/min | 30-150bags/min | |
| Weight | 410kg | 450kg | 490kg | 550kg | 600kg | ||
| Power | 220V,50/60HZ,2.4KVA | ||||||
| Dimension | (L)3770*(W)670*(H)1450mm | (L)3770*(W)720*(H)1450mm | (L)4020*(W)745*(H)1450mm | (L)4020*(W)770*(H)1450mm | (L)4020*(W)820*(H)1450mm | (L)3990*(W)1000*(H)1468mm | |
| Film roll diameter | Max.320mm | ||||||
Features:
1. Double frequency conversion control , bag length can be set and cut in one step , saving time and films.
2. Adopt PLC & HMI programming software , easy operating and setting .
3. Self failure diagnosis , clear failure display .
4. High sensitivity photocell tracing , input cutting & sealing position digitally , extra accuracy .
5. PID control temperature independently which is more suitable for packing different materials .
6. Positioned stop function , without sticking knife or wasting film.
7. Simple driving system , reliable working , convenient maintenance.
8. All control is realized through software , easy for function adjustting , technical upgrade .
Application :
This machine is suitable for pack instant noodle , biscuit , bread , pie , snack , medicine , ice cream , chocolate , mooncake , candy , frozen food , tissue , adhesive tape , soap , commodity , hardware parts , cutlery , inflight meal , etc .
