Down Paper Flow Wrap Machine
| down paper fiow wrap machine | |||||||
| Model | 250X | 350X | 450X | 600X | 700X | 800X | 1000X |
| Film Width | Max.250mm | Max.350mm | Max.450mm | Max.600mm | Max.700mm | Max.800mm | Max.1000mm |
| Bag Width | 30-110mm | 40-160mm | 50-210mm | 50-285mm | 50-335mm | 50-385mm | 60-485mm |
| Bag Length | 65-190mm/150-330mm | 130-580mm | 130-6000mm | ||||
| Product High | Max.35/50mm | Max.60/80/100/140mm | |||||
| Speed | 40-230bags/min | 20-120Bags/min | |||||
| Power | 220V,50/60HZ,2.4KVA | ||||||
| Dimension | (L)3920*(W)670*(H)1320MM | (L)4020*(W)720*(H)1320MM | (L)4400*(W)1100*(H)1460MM | ||||
| Film roll diameter | Max.320mm | ||||||
Features:
1. Double frequency conversion control , bag length can be set and cut in one step , saving time and films.
2. Adopt PLC & HMI programming software , easy operating and setting .
3. Self failure diagnosis , clear failure display .
4. High sensitivity photocell tracing , input cutting & sealing position digitally , extra accuracy .
5. PID control temperature independently which is more suitable for packing different materials .
6. Positioned stop function , without sticking knife or wasting film.
7. Simple driving system , reliable working , convenient maintenance.
8. All control is realized through software , easy for function adjustting , technical upgrade .
Application :
This machine is suitable for pack biscuit , vitellus-pie , wafer biscuit, bread , ice cream , mooncake , candy , medicine , hareware , towels, tissues, noodles, egg rolls, sausage, squid, lollipops, cutlery , inflight meal , etc.
